Products

Two valve manifolds-2VS


With threaded vertical port inlet and outlet.The vent/test connection is positioned on the front side.   The drain bonnet is positioned on the right hand side and the isolating bonnet on the left hand side.


Standard connection

Product

Process side

Instrumentside

Vent/Test

2VS

1/2"NPT female

1/2"NPT female

1/4"NPT female

Remote or direct mounting by means of threaded connections.


The weld prepared types are available with female plain end-suitable for socket weld. Anti-tamper bonnet-special design on request with locking arrangement if desired.
